REMOTE FOR DIGITAL CONTROLLER

JR controller

Since not everyone has a jacket or pants to connect to, the Junior Controller has a built-in “Y” harness which is designed for use with gloves or socks, individually.

** The Junior Controller may only to be used for 5 amps or less (gloves or socks).

**It has four power level indicators: 100 percent is red; 75 percent is amber; 50 percent is green, and 25 percent is blinking green

**Warning: Do not try to put more than one set of heated-clothing items on the same battery harness and controller.

2 YEAR WARRANTY

SAE Female

The SAE Female Plug can be used to connect to your bike's battery tender on one side, while the female coax on the other end connects to your Temperature Controller. This adapter wire is also used if you have an older style of heated clothing that has an SAE connection, and you need to connect to a newer version with a female coax end.

**Using this as your power source with your battery tender connection, you may need to confirm the fuse size on the battery tender cable is sufficient enough to run your gear.

**We do not recommend using your cable as a battery tender wire if you are increasing the fuse to use it for your heated gear.

**Battery harnesses are always recommended first for a power source.

** 8” length

**Max capacity 20 amps

SAE to Coax Male

The SAE Male Plug is generally used for converting most SAE heated clothing plugs to a Coax option.

**8” length

**Max capacity 20 amps

Splitter

The Splitter is typically used when you have a jacket liner and a set of gloves, but only a single temperature controller.

**To install the Splitter, use the two male plugs on your Jacket Liner on the Y end, and plug your temperature controller to the single end.

**Max capacity is 20 amps

**WARNING: A Splitter is not to be used to run 2 sets of heated clothing. Overheating, fire, or damage to your products could occur.

Y Harness

If you don’t have a jacket liner or pants to connect your gloves or socks, the Y Harness is used to make the connection to your controller.

**50” lead for your left side and a 58” lead for your right side

**Max capacity is 20 amps

18” Extension

The Extension Cable provides additional length for your coax connections.

**18” Length

**Max capacity is 20 amps

 Battery Harness

The Battery Harness is used to power your heated gear. It connects to any 12V battery for use on motorcycles, ATV’s, snow mobiles, etc. The battery harness has an inline fuse holder on the positive (red) lead, with a 15 amp fuse included. With a 38” length, there’s ample enough wire for an easy install.

To calculate your true amp draw divide the amp draw on all items you are going to hook

up by 12 them multiply by your motorcycle volt output.

Gloves pull 2.4 amps

Socks pull 2.2 amps

Jacket pulls 6.4 amps

Pants pull 4.6 amps

Connect the red lead to the positive terminal on your battery and the black lead to the negative. Zip

tie the coax plug, leaving about 6” of slack, under your seat on the left side. You may also plug the

battery harness into a panel mount port (sold separately).

**38” length

**15 amp & 20 amp fuse included

**Max capacity 20 amps

90 Degree Coil Cord 3'

When the battery harness plug is just a little too far away and you need a little extra wire, the coil cord gives you the extra you need. The expansion of up to 3 feet helps reach that back seat passenger or give you a little more freedom of movement.

**3 feet (36”) extended length

**Max capacity 20 amps

BMW / Accessory Plug

The Accessory plug is a two-way plug that can be used instead of the battery harness to power your heated clothing. With the red cap on, use your 12-volt accessory port for motorcycles, snowmobiles, boats or cars. Take the red cap off and it becomes a DIN plug that works on your BMW or Triumph accessory port (also known as Powerlet accessory plug).

**32” length

**For use with 12v accessory ports

**Max capacity 20 amps

Panel Mount Port

The Panel Mount Port installed on your motorcycle gives a cleaner look, so you don’t see battery harness wires. Installed on your dashboard or an available panel, it connects to the battery harness on the backside, leaving the once exposed battery harness now behind the scenes and out of the way. A waterproof cap is included when the port is not in use.

Length 8”

Max capacity 20 amps

Drilling required

Existing battery harness required (also sold separately)

7V Y Harness

For use with 7V gloves or socks, the Y Harness is used to make the connection to your 7V batteries. The harness comes standard with the 7V socks. As an alternate to having the batteries in the gauntlet of your gloves, you can use the Y Harness and put your battery in your pocket.

**60” lead for both the right and the left

7V Battery - 3500mAh

A rechargeable 7.4V lithium-ion battery to power your 7V gear - 3500 mAh of power makes it one of the most powerful heated clothing batteries around.

• Four power settings allow temperature control for your comfort
• 25% = 105 degrees F / 50% = 115 degrees F / 75% = 125 degrees F / 100% = 135 degrees F
• Works with many other brands of 7V Battery-Powered heated clothing, including gear with a built-in button to control temperature
• Battery Light Indicator will glow red instead of blue when attached to clothing that has button built-in - power level is then controller via the button
• Lasts at least 3-10 hours on one charge (total time depends on the clothing item & temperature setting)
• Life of the battery is about 500 charges
• To check the remaining charge on the battery, press power button while not attached to heating clothing. The number of Battery light indicators lit will correspond to the charge remaining (0-100%)
• Warranty - 90 days

NOTE: Extreme cold and extended periods of time without use can affect battery life. Charge periodically to at least 25% to extend battery life.

WARNING: Do not leave battery powered gear turned on while unattended. Battery should not be submerged in water.

7V Dual Battery Wall Charger

A Dual Battery Charger for your 7V 2.2Ah and 4Ah lithium ion batteries

**Uses a standard 110v wall socket

**Charger cannot charge two different battery types at the same time. Example: Don't simultaneously charge 2.2Ah and 4Ah batteries

7V Single Battery Wall Charger

A Single Battery Charger for your 7V 2.2Ah and 4Ah lithium ion batteries

**Uses a standard 110v wall socket

7V Dual Battery Car Charger

A Dual Battery Car Charger for your 7V 2.2Ah and 4Ah lithium ion batteries. Plugs into the standard 12V accessory port of cars, boats, motorcycles, ATV’s, etc. to charge your batteries when you’re away from home.

**Uses a standard 12v accessory port

**Charger cannot charge two different battery types at the same time. Example: Don't simultaneously charge 2.2Ah and 4Ah batteries

Hybrid Controller

With the Hybrid Heat Controller you can now power 7V battery-powered heated gear using a Motorcycle, Powersport Vehicle, or any 12V Accessory Port.

• 3 WAYS TO USE

1.  Use a 12V power source to heat a 7V battery-powered item OR a pair of gloves/socks (using a 7V y-harness)
2.  Use a 12V power source to charge a 7V battery
3.  Do both at the same time!

INFO

• Connect to a 12V motorcycle or vehicle battery using a 12V Battery Harness, 12V Accessory Plug, or 12V SAE-COAX Female
• Compatible with other 7V battery-powered brands that use the same plugs, including push-button heated gear
• Charge other brand 7V batteries that use the same plugs
• A dead (fully discharged) 7V battery takes 4-5 hours to fully charge while connected to a 12V power source
• If the controller is disconnected from a 12V power source, the 7V battery will begin powering the 7V clothing - simply turn on the battery then use the controller to change the temperature settings
• Three heat settings:

SPECS

• Input - Connected to 12V Battery: 11V-16V DC
• Output 1 - Charging 7V Battery: 8.4V 1.5A
• *Output 1 becomes a 7V Input powering Output 2 when it is connected to a charged 7V battery but NOT connected to a 12V power source
• Output 2 - Powering 7V Heated Product: 7V 2A max with three output settings (33%-66%-99%)

REQUIRED FOR OPERATION (sold separately)

• 3 Options For Connecting to a 12V Power Source:
• 12V Battery Harness  OR  12V Accessory Plug  OR  12V SAE-COAX Female

WARRANTY

All controllers are covered by a 2 year warranty.

12V RCA to Female Coax Adapter

The 12V RCA to Female COAX Adapter allows you to power your heated gear using snowmobiles or other vehicles with an RCA port.

This adapter can be used with the heated visor plug installed on your vehicle.

• 10" length

• Fits 5.5 x 2.5mm heated clothing plugs

REQUIRED FOR OPERATION (sold separately)

12V Temperature Controller

WARNING: Each person must have their own temperature and power adapter (Battery Harness, Accessory Plug, etc). Using only one controller and/or power cable for more than one individual's heated outfit may overload the 12V battery or controller and could result in damage to the products, cause them to malfunction, and/or cause bodily harm.

12V On/Off Switch

The 12V On/Off Switch is used as a backup to control the heat of your heated gear. When turned on your heated clothing will be heated at full strength (+135°F). When turned off there will be no heat.

The On/Off Switch is an alternative option in case something happens to your main temperature controller and you need heat in a pinch.

• 12" length
• Not recommended as a permanent heat control solution due to the lack of temperature controls
• May cause burns with continuous, long-term use

REQUIRED FOR OPERATION (sold separately)

12V Battery Harness  OR 12V Accessory Plug

WARNING: Failure to use product(s) as instructed or alter them in any way could result in damage to the products, cause them to malfunction, and/or cause bodily harm.

12V Female Adapter Plugs

The Female Adapter plug allows you to connect California Heat 12V gear to other brands using inverted versions of the same plugs. You can also pair previous generations of Harley gloves and socks with our jackets and pants for a single, seamless outfit.

• Sold as a pair
• Fits 5.5mm x 2.5mm plugs

WARNING: Failure to use product(s) as instructed or alter them in any way could result in damage to the products, cause them to malfunction, and/or cause bodily harm.
